SIMAGIC EVO Ultra 28Nm - Ultra high performance Direct Drive sim racing wheel base
The SIMAGIC EVO Ultra 28Nm is a Direct Drive sim racing wheel base developed for drivers looking for extremely high levels of precision and responsiveness. Thanks to its ultra-low inertia servo motor and Zero-Cogging technology, this Direct Drive wheel base reproduces track details with exceptional smoothness and accuracy to deliver highly detailed force feedback on the most demanding PC racing simulations.
A Direct Drive wheel base built to push the limits
28 Nm and ultra-low inertia motor technology
With its maximum torque of 28 Nm and 550 W motor power, the SIMAGIC EVO Ultra 28Nm delivers highly immersive and powerful force feedback. Its ultra-low inertia servo motor improves responsiveness to instantly reproduce grip loss, vibrations and weight transfer on high-end sim racing setups.
21-bit magnetic encoder and 20 kHz control frequency
The 21-bit magnetic encoder improves the precision of the sim racing wheel by capturing micro steering variations with exceptional accuracy. Combined with a 20 kHz control frequency, this technology minimizes latency and delivers especially smooth and responsive force feedback.
DFDF Algorithm and advanced FFB management technologies
The Dynamic Force Domain Filter dynamically optimizes the FFB curve to preserve fine details during rapid torque changes. Dynamic Prediction, Slew Rate Control and Zero-Cogging technologies further improve motor stability to provide more natural steering behavior and greater driving precision in sim racing.
Extended connectivity and broad compatibility
Featuring 11 USB, CAN, CAN FD, RJ45 and RJ11 ports, the SIMAGIC EVO Ultra allows multiple sim racing peripherals such as dashboards, pedal sets, shifters and accessories to be connected simultaneously. This Direct Drive wheel base also supports magnetic dashboards, third-party peripherals and multiple mounting solutions for profile rigs, front mounts and bottom mounts.
SIMAGIC EVO Ultra 28Nm technical specifications
- SIMAGIC EVO Ultra Direct Drive wheel base
- Maximum torque: 28 Nm
- Motor power: 550 W
- Direct Drive motor with ultra-low inertia
- 21-bit magnetic encoder
- Control frequency: 20 kHz
- Zero-Cogging Technology
- Dynamic Force Domain Filter (DFDF)
- Dynamic Prediction and Slew Rate Control
- Hyper Cool active cooling system
- 11 ports including USB, CAN, CAN FD, RJ45 and RJ11
- Halo RGB intelligent lighting
- Compatible with third-party sim racing wheels
- Compatible with PC and major racing simulators
- Integrated 2.4 GHz Bluetooth
- Dimensions: 359 x 130 x 110 mm
- Weight: 11 kg
- CNC-machined aluminum + ABS construction
- SimPro Manager software
| SKU | S107 |
|---|---|
| Product Type | Wheel Base |
| Compatibility | PC |
| Force Feedback | Direct Drive |
| Torque | 28 Nm |
| Quick Release | Yes |
| Mount method | Central, Latéral, Wheelbase |
| Ports | Shifter, Dashboard, Handbrake, Pedals, USB |
| Rated Power | 550 W |
| Input Voltage | AC 100–240V universelle |
| Warranty | 2 ans |
| Eco Taxe DEEE | €1.67 |
| EAN13 | 697547277152 |
